Description

Features

• A2 aluminum frame featuring updated geometry to meet today’s standards
• SR Suntour front suspension fork with 100mm of travel
• Shimano Tourney 3×7 speed drivetrain
• Tektro HD-M280 mechanical disc brakes with 160mm rotors
• WTB SX19 wheelset with WTB Ranger Comp 29″x2.25″ tires



Specifications

Sizes: XS (13″), S (15″), M (17″), L (19″)

Color(s): Satin Graphite, Dark Teal

Frame: Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle

Fork: SR Suntour SF19-XCE 27.5, 100mm OR ZOOM 525AMS

Crankset: Prowheel, 42/34/24T

Bottom Bracket: Sealed cartridge bearing

Pedals: Resin platform

Front Derailleur: Shimano Tourney OR microSHIFT Mezzo

Rear Derailleur: Shimano Tourney OR microSHIFT RD-M26CL

Shifters: Shimano EF41, EZ Fire, 3 x 7-speed OR microSHIFT TS-39

Cassette: Shimano TZ500 freewheel, 14-34T OR SunRace MFM-300

Chain: KMC HV500

Wheelset: WTB SX19 rims 32H, Formula DC-20 front, DC-31 rear hubs, black spokes

Tires: WTB Ranger Comp, 27.5″ x 2.25″, 27tpi OR Good Year Peak Premium OR Seoyun 2.1″

Brakeset: Tektro M280, mechanical disc, 160mm rotors

Brake Levers: Shimano EF41 OR Tektro RS360A

Headset: 1 1/8″ sealed bearings

Handlebar: Fuji riser bar, alloy, 15mm rise, 710mm

Stem: Fuji, forged aluminum, +/-6°

Grips: Fuji Performance Grip

Saddle: Fuji Performance Saddle OR WTB OR SELLE ROYAL March 2

Seat post: Fuji, alloy, 30.9mm

*Specifications subject to change without notice

Geometry

View Size Guide

	Size	XS	S	M	L
	Bike Size	13″	15″	17″	19″
A	Seat Tube, Center To Top	310	370	420	470
C	Top Tube, Effective	562	581	601	629
D	Head Tube Length	95	100	110	120
E	Seat Tube Angle	73°	73°	73°	73°
G	Head Tube Angle	69.5°	69.5°	69.5°	69.5°
H	Chainstay Length	440	440	440	440
I	Wheelbase	1068.5	1087	1109	1137
J	Bottom Bracket Drop	45	45	45	45
K	Fork Offset	42	42	42	42
M	Stack	596	600	610	619
N	Reach	380	397	415	440
O	Standover	737	767	795	823
