Description

Features

• A2 aluminum frame featuring updated geometry to meet today’s standards
• SR Suntour SF19-XCT30-HLO-DS-29 suspension fork with 100mm of travel
• SRAM x4 3×8 speed drivetrain
• Tektro HD-M275 brakes with 180/160mm rotors
• WTB SX19 wheelset with WTB Ranger Comp 29″x2.25″ tires



Specifications

Sizes: XS (13″), S (15″), M (17″), L (19″)

Color(s): Satin Graphite, Dark Teal

Frame: Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle

Fork: SR Suntour SF19-XCT30-HLO-DS-29, hydraulic lockout, 100mm

Crankset: Prowheel, 42/34/24T

Bottom Bracket: Sealed cartridge bearing

Pedals: Resin platform

Front Derailleur: Microshift FD-M20

Rear Derailleur: SRAM X4

Shifters: SRAM X4, 3 x 8-speed

Cassette: Sunrace CSM66, 11-34T

Chain: KMC HV700

Wheelset: WTB SX19 rims 32H, Formula DC-20 front, DC-22 rear hubs, black spokes

Tires: WTB Ranger Comp, 29″ x 2.25″, 27tpi

Brakeset: Tektro HD-M275, 180/160mm rotors

Brake Levers: Tektro HD-M275

Headset: 1 1/8″ sealed bearings

Handlebar: Fuji flat bar, alloy, 710mm

Stem: Fuji, forged aluminum, +/-6°

Grips: Fuji Performance Grip

Saddle: Fuji Performance Saddle

Seat post: Fuji, alloy, 30.9mm

*Specifications subject to change without notice

Geometry

View Size Guide

	Size	XS	S	M	L
	Bike Size	13″	15″	17″	19″
A	Seat Tube, Center To Top	310	370	420	470
C	Top Tube, Effective	562	581	601	629
D	Head Tube Length	95	100	110	120
E	Seat Tube Angle	73°	73°	73°	73°
G	Head Tube Angle	69.5°	69.5°	69.5°	69.5°
H	Chainstay Length	440	440	440	440
I	Wheelbase	1068.5	1087	1109	1137
J	Bottom Bracket Drop	45	45	45	45
K	Fork Offset	42	42	42	42
M	Stack	596	600	610	619
N	Reach	380	397	415	440
O	Standover	737	767	795	823
