BMC Teammachine SLR Frameset V1 – Carbon/Prisma

Description

This Teammachine SLR Carbon frame and fork has been created with TCC Race technology, a D-Shape Carbon seatpost, Stealth Dropouts and comes ready to take internal cable routing. The platform of choice for those looking to benefit from this bike’s proven performance while building their dream Teammachine.



Technical Overview

Full Specifications

• Frame

  Teammachine SLR Carbon with Aerocore Design
  Stealth Dropout Design
  TCC Race Compliance Level
  PF86 Bottom Bracket
  Flat Mount Disc
  12x142mm Thru-Axle
  Optimized for Aerocore Bottle Cages

• Fork

  Teammachine SLR Carbon
  TCC Race Compliance Level
  Internal Cable Routing
  Flat Mount Disc
  Stealth Dropout Design
  12x100mm Thru-Axle

• Seatpost

  Teammachine SLR Carbon D-Shaped Seatpost
  15mm Offset

• Tire Clearance

  30mm (Measured Width)

• Weight Limit

  110 Kg

• ASTM Classification

  Level 1

Geometry

Size	47	51	54	56	58	61
Rider Height CM	<166	166-174	172-180	178-186	184-192	>190
Stack MM	506	530	550	565	584	608
Reach MM (reach)	367	377	386	392	401	409
Seat Tube MM (st)	423	468	504	524	545	574
Top Tube MM (tt)	517	534	549	559	574	589
Head Tube MM (ht)	110	130	145	165	184	210
Seat Tube Angle (sa)	73.5	73.5	73.5	73.5	73.5	73.5
Head Angle (ha)	71.5	71.5	72.3	72.3	72.3	72.3
Rear Center MM (rc)	410	410	410	410	410	410
Front Center MM (fc)	568	586	589	599	614	630
Wheelbase MM (wb)	968	986	989	1000	1015	1030
BB Drop MM (drop)	69	69	69	69	69	69
Fork Length MM (fl)	368	368	368	368	368	368
Fork Rake MM (fr)	48	48	43	43	43	43
Trail MM (trail)	63	63	63	63	63	63
Post Offset MM	15	15	15	15	15	15
Standover Height mm	717	752	779	797	817	843
Seatpost Length MM	330	380	380	380	380	380



Technical Details & Manuals

Frameset

• Teammachine SLR ACE carbon frame with Aerocore design, Tuned Compliance Concept Race
• Teammachine SLR ACE carbon fork with Aerocore design, Tuned Compliance Concept Race
• Teammachine SLR ACE carbon D-shape seatpost

Teammachine SLR features classic, round steerer forks. Models equipped with ICS stems use dedicated components that are adapted for use on round steerer forks.*

Technical Details

• Aerocore: aerodynamic featherweight carbon bottle cage system (available upgrade)
• Downtube bottle cage
• Seat tube bottle cage
• Internal cable management
• Integrated seat clamp
• Easy access Di2 junction box integrated in downtube
• Stealth droputs with dedicated stealth thru-axles
• ASTM level 1

Only use stealth thru-axles provided with Teammachine SLR01 and Teammachine SLR bikes and modules. Stealth dropouts and thru-axles are compatible with most direct-drive indoor trainers.*

Sizes

47, 51, 54, 56, 58, 61

Frame Weight**
990 g

Fork Weight**
375 g

Seatpost Weight**
195 g

Cockpit

ICS01 Stem with RAB02 Bar

• Integrated Cockpit System stem with internal cable routing and easy fit adjustment
• Handlebar reach/drop: 70/125 mm (RAB02)
• ICS01 Stem Angle: -12.5
• 200 g (stem)

RSM01 Stem with RAB02 Bar

• Classic stem and bar combination
• Handlebar reach/drop: 70/125 mm (RAB02)
• Stem Angle: ¬±8 (RSM01)

Teammachine SLR models equipped with ICS stems use an adapted version for use on round steerer forks.*

Compatibility

Frame, Fork and Seatpost

• Tapered fork with round 1-1/8″ steerer, flat mount
• Compatible with electronic and mechanical groupsets
• PF86 bottom bracket
• D-Shape seatpost
• Braze-on front derailleur mount
• Replaceable ultra light sandwich rear derailleur hanger

Brakes

• Front brake: flat mount, 160 mm rotors only
• Rear brake: flat mount, 140/160 mm rotors

Wheels and Axles

• Designed for 25 mm, maximum tire clearance 30 mm (actual measured width)
• Front stealth thru-axle: 12×100 mm (diameter/frame spacing)
• Rear stealth thru-axle: 12×142 mm (diameter/frame spacing)

*Notes about proprietary technology

**Weight for the lightest finish, including complete hardware with size 54 frames
